Spare parts high intensity lamps

Clay burner HK350/HK500

The durable clay burner for the Petromax HK350 and HK500.

Nozzle needle HK500

This nozzle needle is suitable for Petromax model HK500.

Air Pump Adapter HK150/HK250/HK350/HK500 Chrome

The air pump adapter simplifies the pumping up of the lamp, in which it is exchanged for the hand pump. To do this, the pump cover is unscrewed together with the piston and the air pump adapter is screwed on. An air pump or compressor can then be connected to the adapter to quickly and conveniently pressurize the tank. If the lamp is pumped up with the help of the adapter, this also benefits the service life of the filament. Shocks caused by pumping with the hand pump are thus avoided. The air pump adapter fits all Petromax models: HK150/250/350/500.

Preheating tray HK250/HK350/HK500 chrome

This chrome-colored preheating bowl is filled with spirit to preheat the lamp. It is suitable for Petromax models HK250/350/500.

Viton gasket carburetor & rapid preheater HK150/HK250/HK350/HK500

Made of Viton, the gasket is suitable for sealing the screw connections of the carburetor and rapid preheater of all Petromax models. Its advantage is that it can be used several times. Viton is also resistant to gasoline, so this gasket is suitable to repair old gasoline lamps.

Inner sheath HK350/HK500

The inner sheath consists of a thrust piece, yoke, a screw, mixing tube and chamber, and the clay burner. These components have already been assembled and are available as a complete inner cover. All parts can also be replaced individually and are also available.

Nozzle HK500

This nozzle is suitable for Petromax model HK500.

Pump leather HK150/HK250/HK350/HK500

This pump leather is suitable for all Petromax models HK150/250/350/500. Before installation, the pump leather should be greased and kneaded soft. The pure technical petroleum jelly from Petromax (#vas) is suitable for this.

Carburetor & Gasket HK350/HK500

The carburetor is the heart of every Petromax lamp.It is composed of guide rod, eccentric, carburetor valve, nozzle needle, sealing ring and carburetor top and bottom parts. The carburetor is already completely assembled here and can be installed directly in the Petromax lamp.All parts are also individually replaceable and available.

Air pump adapter HK150/HK250/HK350/HK500 brass

The air pump adapter simplifies pumping up the lamp by replacing it with the hand pump. To do this, unscrew the pump cover together with the piston and screw on the air pump adapter. An air pump or compressor can then be connected to the adapter to quickly and conveniently pressurize the tank. If the lamp is pumped up with the help of the adapter, this also benefits the service life of the bulb. Shocks caused by pumping with the hand pump are thus avoided. The air pump adapter fits all Petromax models: HK150/250/350/500.

Mixing tube HK350/500

The brass tube, bent in a U-shape, is installed in the inner jacket. The fuel and the air drawn in from outside are mixed in the mixing tube. The fuel-air mixture finally reaches the burner via the mixing chamber connected to it.Since the mixing tube expands and contracts again as it heats up and cools down, the mixing tube distance to the carburetor nozzle must be readjusted every now and then to ensure an optimum mixture.

Socket with seal & screw HK150/HK250/HK350/HK500

The socket with seal and screw is a component of the rocker arm and thus of the rapid preheater.

Rocker arm & parts HK150/HK250/HK350/HK500 chrome

The toggle lever is used to manually open and close the rapid. When closing, it presses on the nozzle and ensures that no fuel escapes. The rocker arm here is already equipped with the socket with seal and screw, which is also available separately.

Nozzle Rapid preheater HK150/HK250/HK350/HK500

This nozzle is part of the raid and, due to the pressure built up in the tank, ensures the nebulization/atomization of the petroleum, which is mixed with air in the flame protection tube and ignited. It can be installed in all Petromax models.

Carburetor upper part HK350/HK500

The upper part of the carburetor is part of the carburetor. There is a thread for the carburetor nozzle above the carburetor helix, and the lower part of the carburetor is fastened at the lower end by means of a union nut.

Pump piston plate HK150/HK250/HK350/HK500

This pump piston plate is suitable for all Petromax models HK150/250/350/500.

Pump knob HK150/HK250/HK350/HK500 blue

This classic pump knob in blue is adorned with a gold-colored Petromax lettering. It is suitable for all Petromax models HK150/250/350/500.

Rapid preheater HK350/HK500 brass

The Rapid Preheater consists of a total of eight individual parts. Here it is already completely assembled and can be installed directly in the Petromax lamp.All parts are also individually replaceable and available.

Connection body HK350/HK500

The connection body is a component of the Rapid preheater and consists of three individual parts. Here it is already completely assembled and can be installed directly with the other parts of the Rapid preheater in the Petromax lamp.All parts are also individually replaceable and available.

Nozzle nut Rapid preheater HK150/HK250/HK350/HK500

This nozzle nut is part of the raid and is responsible for fixing the rocker arm. It can be installed in all Petromax models.

Support Bracket HK350/HK500

This support bracket is used to convert the Petromax HK350/500 to operation with two-hole glow mantles. The double attachment of the two-hole incandescent mantle to the support bracket provides comparatively more stability for the incandescent mantle. When installing the support bracket, the clay burner should also be replaced with the VA burner (#3-va-500).

Locking screw HK150/HK250/HK350/HK500

This locking screw is suitable for all Petromax models HK150/250/350/500.

Preheating tray HK250/HK350/HK500 brass

This brass colored preheating bowl is filled with spirit to preheat the lamp. It is suitable for Petromax models HK250/350/500.

Washer Handwheel HK150/HK250/HK350/HK500

The washer without embossing for all Petromax strong light lamp models HK150/HK250/HK350/HK500.

Rapid preheater HK350/HK500 chrome

The Rapid Vorwämer consists of a total of eight individual parts. Here it is already completely assembled and can be installed directly in the Petromax lamp.All parts are also individually replaceable and available.

Flame protection tube HK150/HK250/HK350/HK500

The flame tube is part of the rapid igniter, which is installed in the Petromax models. It is responsible for bringing the flame into shape, so that it does not strike out uncontrollably. Furthermore, the petroleum coming out of the nozzle mixes with air in the flame tube, which can flow in through the holes in the tube. It can be installed in all Petromax models.

Carrying frame HK350/HK500 chrome

The carrying frame serves as a holder for the glass cylinder as well as for the entire upper part of the lamp with the loose-fitting inner jacket. The rack is mounted on the tank with centering base and centering base screw.The carrying rack allows the Petromax lamp to be easily and safely carried, placed or hung.

Baffle plate HK350/HK500 brass

The baffle plate is a useful and recommended accessory for any Petromax strong light lamp. In the event of a defective glow plug, small but very hot flames can spread in the lamp and loosen solder joints on the tank. The baffle plate, which is inserted into the carrying frame above the centering base, shields the tank. The protective baffle plate ensures that the tank remains intact even if the filaments are damaged. The baffle plate is also required for mounting the Petromax radiator. This baffle plate is manufactured for lamps from year of manufacture 2000. These can be recognized by the screwed support rods of the support frame. For lamps before year of manufacture 2000, the support rods are riveted to the frame.

Universal wrench HK150/HK250/HK350/HK500

This universal wrench can be used to loosen many screw connections of the Petromax models HK150/250/350/500 so that maintenance and adjustment work can be carried out.

Pump piston nut HK150/HK250/HK350/HK500

This pump piston nut is suitable for all Petromax models HK150/250/350/500.

Pump piston rod HK150/HK250/HK350/HK500

This pump piston rod is suitable for all Petromax models HK150/250/350/500.

Pump cover HK150/HK250/HK350/HK500 brass

This brass colored pump cover is suitable for all Petromax models HK150/250/350/500.

Pump cover HK150/HK250/HK350/HK500 chrome

This chrome colored pump cover is suitable for all Petromax models HK150/250/350/500.

Rocker arm & parts HK150/HK250/HK350/HK500 brass

The toggle lever is used to open and close the rapier manually. When closing, it presses on the nozzle and ensures that no fuel escapes. The rocker arm here is already equipped with the socket with seal and screw, which is also available separately.

Yoke mixing tube HK250/HK350/HK500

This yoke is suitable for the mixing tube of Petromax models HK250/350/500.

Screw thrust piece HK250/HK350/HK500

This screw for the pressure piece (#20) is suitable for Petromax models HK250/350/500.

Centering base HK350/500 brass

The centering base serves as a connecting piece between the tank and the carrying frame and is fixed with the centering base screw. It has recesses for the carburetor and the rapid starter as well as a row of holes to ensure cooling of the tank by the resulting air draft when the lamp is in operation.

Centering base HK350/HK500 chrome

The centering base serves as a connecting piece between the tank and the carrying frame and is fixed with the centering base screw. It has recesses for the carburetor and the rapid starter as well as a row of holes to ensure cooling of the tank by the resulting air draft when the lamp is in operation.

Carrying frame HK350/HK500 brass

The carrying frame serves as a holder for the glass cylinder as well as for the entire upper part of the lamp with the loose-fitting inner jacket. The rack is mounted on the tank with centering base and centering base screw.The carrying rack allows the Petromax lamp to be easily and safely carried, placed or hung.

Pressure gauge seal HK150/HK250/HK350/HK500

Gauge seal, suitable for all Petromax models HK150/250/350/500.

Graphite packing HK150/HK250/HK350/HK500

This graphite packing is suitable for Petromax models HK150/250/350/500.

Pump valve insert HK150/HK250/HK350/HK500

This pump valve insert with rubber piece is suitable for Petromax models HK150/250/350/500.

Needle wrench HK150/HK250/HK350/HK500

The needle wrench is used to assemble and disassemble the nozzle needle of the carburetor for the Petromax models HK150/HK250/HK350/HK500.

Pressure gauge HK150/HK250/HK350/HK500 chrome

The pressure gauge is inserted into the upper part of the tank. The manometer seal ensures that the recess is sealed airtight when inserted and that there is no pressure loss. On the scale between 0 and 3 bar, the optimum operating pressure is indicated by a red mark. The pressure gauge is also equipped with a bleed screw to reduce the pressure if necessary.

manual cleaning needle HK150/HK250/HK350/HK500

This manual cleaning needle can be used to clean the nozzle of the Rapid preheater of all Petromax models HK150/250/350/500.

Spring pump valve HK150/HK250/HK350/HK500

This pump valve insert with rubber piece is suitable for Petromax models HK150/250/350/500.

Pressure gauge HK150/HK250/HK350/HK500 Brass

The pressure gauge is inserted into the upper part of the tank. The manometer seal ensures that the recess is sealed airtight when inserted and that there is no pressure loss. On the scale between 0 and 3 bar, the optimum operating pressure is indicated by a red mark. The pressure gauge is also equipped with a bleed screw to reduce the pressure if necessary.

Handwheel blue HK150/HK250/HK350/HK500

This blue handwheel with Petromax lettering is suitable for the Petromax models HK150/250/350/500.

Preheating tray HK250/HK350/HK500 chrome

This chrome-colored preheating bowl is filled with spirit to preheat the lamp. It is suitable for Petromax models HK250/350/500.

Pump valve insert HK150/HK250/HK350/HK500

This pump valve insert with rubber piece is suitable for Petromax models HK150/250/350/500.

Pressure gauge seal HK150/HK250/HK350/HK500

Gauge seal, suitable for all Petromax models HK150/250/350/500.

Graphite packing HK150/HK250/HK350/HK500

This graphite packing is suitable for Petromax models HK150/250/350/500.

Pressure gauge HK150/HK250/HK350/HK500 chrome

The pressure gauge is inserted into the upper part of the tank. The manometer seal ensures that the recess is sealed airtight when inserted and that there is no pressure loss. On the scale between 0 and 3 bar, the optimum operating pressure is indicated by a red mark. The pressure gauge is also equipped with a bleed screw to reduce the pressure if necessary.

Needle wrench HK150/HK250/HK350/HK500

The needle wrench is used to assemble and disassemble the nozzle needle of the carburetor for the Petromax models HK150/HK250/HK350/HK500.

Nozzle needle HK250

This nozzle needle is suitable for Petromax model HK250.

manual cleaning needle HK150/HK250/HK350/HK500

This manual cleaning needle can be used to clean the nozzle of the Rapid preheater of all Petromax models HK150/250/350/500.

Spring pump valve HK150/HK250/HK350/HK500

This pump valve insert with rubber piece is suitable for Petromax models HK150/250/350/500.

Nozzle HK250

This nozzle is suitable for Petromax model HK250.

Universal wrench HK150/HK250/HK350/HK500

This universal wrench can be used to loosen many screw connections of the Petromax models HK150/250/350/500 so that maintenance and adjustment work can be carried out.

Pressure gauge HK150/HK250/HK350/HK500 Brass

The pressure gauge is inserted into the upper part of the tank. The manometer seal ensures that the recess is sealed airtight when inserted and that there is no pressure loss. On the scale between 0 and 3 bar, the optimum operating pressure is indicated by a red mark. The pressure gauge is also equipped with a bleed screw to reduce the pressure if necessary.

Handwheel blue HK150/HK250/HK350/HK500

This blue handwheel with Petromax lettering is suitable for the Petromax models HK150/250/350/500.

Pressure gauge glass HK150/HK250/HK350/HK500

The round cover made of PMMA (acrylic glass) serves as a replacement for a damaged viewing window on the pressure gauge. The shatterproof, transparent plastic part protects the display from dirt and damage.

Preheating tray HK250/HK350/HK500 brass

This brass colored preheating bowl is filled with spirit to preheat the lamp. It is suitable for Petromax models HK250/350/500.

Pump piston nut HK150/HK250/HK350/HK500

This pump piston nut is suitable for all Petromax models HK150/250/350/500.

Nozzle nut Rapid preheater HK150/HK250/HK350/HK500

This nozzle nut is part of the raid and is responsible for fixing the rocker arm. It can be installed in all Petromax models.

Washer Handwheel HK150/HK250/HK350/HK500

The washer without embossing for all Petromax strong light lamp models HK150/HK250/HK350/HK500.

Pressure gauge screw HK150/HK250/HK350/HK500 Chrome

The bleed screw is located on the pressure gauge. It is responsible for maintaining the operating pressure or reducing it if necessary.

Groove handwheel HK150/HK250/HK350/HK500

This nut is suitable for the handwheels of all Petromax models HK150/250/350/500.

Flame protection tube HK150/HK250/HK350/HK500

The flame tube is part of the rapid igniter, which is installed in the Petromax models. It is responsible for bringing the flame into shape, so that it does not strike out uncontrollably. Furthermore, the petroleum coming out of the nozzle mixes with air in the flame tube, which can flow in through the holes in the tube. It can be installed in all Petromax models.

Exzenternippel HK150/HK250/HK350/HK500

This eccentric nipple is suitable for the Petromax models HK150/250/350/500.

Pump cover HK150/HK250/HK350/HK500 chrome

This chrome colored pump cover is suitable for all Petromax models HK150/250/350/500.

Union nut eccentric HK150/HK250/HK350/HK500

This union nut is the central component of the eccentric. It is suitable for Petromax models HK150/250/350/500.

Screw thrust piece HK250/HK350/HK500

This screw for the pressure piece (#20) is suitable for Petromax models HK250/350/500.

Eccentric (complete) HK150/HK250/HK350/HK500

This complete eccentric with blue handwheel is suitable for Petromax models HK150/250/350/500.

Pump piston rod HK150/HK250/HK350/HK500

This pump piston rod is suitable for all Petromax models HK150/250/350/500.

Yoke mixing tube HK250/HK350/HK500

This yoke is suitable for the mixing tube of Petromax models HK250/350/500.

Locking screw HK150/HK250/HK350/HK500

This locking screw is suitable for all Petromax models HK150/250/350/500.

Pressure gauge screw HK150/HK250/HK350/HK500 brass

The bleed screw is located on the pressure gauge. It is responsible for maintaining the operating pressure or reducing it if necessary.

Rocker arm & parts HK150/HK250/HK350/HK500 brass

The toggle lever is used to open and close the rapier manually. When closing, it presses on the nozzle and ensures that no fuel escapes. The rocker arm here is already equipped with the socket with seal and screw, which is also available separately.

Pump cover HK150/HK250/HK350/HK500 brass

This brass colored pump cover is suitable for all Petromax models HK150/250/350/500.

Pump valve insert HK150/HK250/HK350/HK500

This pump valve insert with rubber piece is suitable for Petromax models HK150/250/350/500.

Pressure gauge seal HK150/HK250/HK350/HK500

Gauge seal, suitable for all Petromax models HK150/250/350/500.

Graphite packing HK150/HK250/HK350/HK500

This graphite packing is suitable for Petromax models HK150/250/350/500.

Pressure gauge HK150/HK250/HK350/HK500 chrome

The pressure gauge is inserted into the upper part of the tank. The manometer seal ensures that the recess is sealed airtight when inserted and that there is no pressure loss. On the scale between 0 and 3 bar, the optimum operating pressure is indicated by a red mark. The pressure gauge is also equipped with a bleed screw to reduce the pressure if necessary.

Needle wrench HK150/HK250/HK350/HK500

The needle wrench is used to assemble and disassemble the nozzle needle of the carburetor for the Petromax models HK150/HK250/HK350/HK500.

manual cleaning needle HK150/HK250/HK350/HK500

This manual cleaning needle can be used to clean the nozzle of the Rapid preheater of all Petromax models HK150/250/350/500.

Spring pump valve HK150/HK250/HK350/HK500

This pump valve insert with rubber piece is suitable for Petromax models HK150/250/350/500.

Nozzle needle HK150

This nozzle needle is suitable for Petromax model HK150.
